std::default_random_engine eng;
std::normal_distribution<double> dist(5.0,2.0);
// mean 5, standard deviation 2
array<int,10> tmp = {0, };
//initialize with zero and set the array size of 10
for (int i = 0; i < 10000; ++i) {
double number = dist(eng);
if((number>= 0.0) &&(number <10.0)) ++tmp[int(number)];
}
/*
function taking GPS position and initial heading as input.
output: print out to the terminal 3 samples from a normal distribution with mean equal to the GPS position
and initial heading measurements and standard deviation of 2 m for the x and y position and 0.05 radians for the heading of the car.
*/
#include <iostream>
#include <random>
using namespace std;
using std::normal_distribution;
void printSamples(double gps_x, double gps_y, double theta);
int main() {
// set GPS provided state of the car
double gps_x = 4983;
double gps_y = 5029;
double theta = 1.201;
printSamples(gps_x, gps_y, theta);
return 0;
}
void printSamples(double gps_x, double gps_y, double theta) {
std::default_random_engine gen;
double std_x, std_y, std_theta;
/*
stadard deviation of x: 2m
standard deviation of y: 2m
standard deviation of theta: 0.05 radians
*/
std_x = 2;
std_y = 2;
std_theta = 0.05;
normal_distribution<double> dist_x(gps_x, std_x);
normal_distribution<double> dist_y(gps_y, std_y);
normal_distribution<double> dist_theta(theta, std_theta);
for (int i = 0; i < 3; ++i) {
double sample_x, sample_y, sample_theta;
// TODO: sample from these normal distributions like this:
sample_x = dist_x(gen);
sample_y = dist_y(gen);
sample_theta = dist_theta(gen);
// where "gen" is the random
cout << "sample" << i + 1 << "" << sample_x << "" << sample_y << sample_theta << endl;
}
return;
}
#define _USE_MATH_DEFINES
#include <cmath>
#include <iostream>
#include <math.h>
using namespace std;
int main() {
double x_part, y_part, x_obs, y_obs, theta;
x_part = 4;
y_part = 5;
x_obs = 2;
y_obs = 2;
theta = -M_PI / 2;
double x_map;
x_map = x_part + (cos(theta) * x_obs) - (sin(theta) * y_obs); //x_obs,y_obs are car coordinates.
double y_map;
y_map = y_part + (sin(theta) * x_obs) + (cos(theta) * y_obs);
cout << int(round(x_map)) << ',' << int(round(y_map)) << endl;
return 0;
}
After transforming observation into map coordinate, this step associates the transformed observation with the nearest landmark.
#define _USE_MATH_DEFINES
#include "multivariate_gaussian_particle_weight.h"
#include <cmath>
double multiv_prob(double sig_x, double sig_y, double x_obs, double y_obs, double mu_x, double mu_y) {
double gauss_norm;
gauss_norm = 1 / (2 * M_PI * sig_x * sig_y);
double exponent;
exponent = (pow(x_obs - mu_x, 2) / (2 * pow(sig_x, 2))) + (pow(y_obs - mu_y, 2) / (2 * pow(sig_y, 2)));
double weight;
weight = gauss_norm * exp(-exponent);
return weight;
}
void ParticleFilter::resample() {
/** TODO: Resample particles with replacement with probability proportional
* to their weight.
* NOTE : You may find std::discrete_distribution helpful here.
* http ://en.cppreference.com/w/cpp/numeric/random/discrete_distribution
* https://robotics.stackexchange.com/questions/479/particle-filters-how-to-do-resampling
* http://cecas.clemson.edu/~ahoover/ece854/lecture-notes/lecture-pf.pdf
* https://www.youtube.com/watch?v=aHLslaWO-AQ
*
*/
for (int i = 0; i < particles.size(); ++i)
{
cout << "weight:" << particles[i].weight << endl;
}
unsigned seed = std::chrono::system_clock::now().time_since_epoch().count(); // creating seed
std::default_random_engine gen_resample(seed);
std::uniform_real_distribution<> ranN(0, 1);
int index;
int N = particles.size();
index = int(ranN(gen_resample) * N);
double beta = 0.0;
double mw = 0.0;
std::vector<Particle> p3;
for (int j = 0; j < N; j++)
{
mw = max(particles[j].weight, mw);
}
double max_weight = mw; //obtain maximum weight
for (int i = 0; i < N; i++)
{
beta = beta + ranN(gen_resample) * 2 * max_weight;
while (particles[index].weight < beta) {
beta = beta - particles[index].weight;
index = (index + 1) % N;
}
p3.push_back(particles[index]);
}
particles = p3;
}
